Nuphy Air75V3 Low Profile Mechanical Keyboard Kit

$185.00 SGD

Shipping calculated at checkout.

Colour: Nova white

Nova white Nebula Dark

Switch: Red Nano

Red Nano Brown Nano Blush Nano

Product variants

Pickup available at Yu Li Industrial Building

Usually ready in 24 hours

The NuPhy Air75 V3 is an ultra-slim low-profile 75% wireless mechanical keyboard engineered for maximum portability and premium typing. It features an CNC-machined aluminum frame, an innovative hot-swappable rotary knob, a gasket-mounted design for a creamy sound profile.

Specifications

Layout: ANSI 75%
Number of Keys: 84
Switch Type: Low-profile
Stabilizer Type: Plate Mounted
Mount Type: Gasket
Hot-swappable Support: Yes
N-key Rollover Support: Yes
Backlight: North-facing RGB-LED
Backlight Modes: 20
Compatible System: macOS/Windows/Android/iOS
Operating Environment: -10 to 50℃

Connection Modes

Mode: 2.4GHz, Wired (USB-C) or Bluetooth 5.0
2.4GHz Polling Rate: 1000Hz
Wired Polling Rate: 1000Hz
Bluetooth 5.0 Polling Rate: 125Hz

Materials

Top Case: Aluminum
Bottom Case: ABS
Plate Material: PC
Keycap: Double-shot PBT

Size and Weight

318.9 mm x 128.9 mm x 13.2 mm
(12.56 inches x 5.07 inches x 0.52 inches)
724 grams (1.6 pound)
Type Angle 4º/8º/10º

Power & Battery

Battery Capacity: 4000mAh
Working Time (all lights on): 60~100 hours (lab test result)
Working Time (all lights off): Up to 1200 hours (lab test result)

Switch Specifications

Red Nano (Linear)

Operating Force: 45± 15gf
End Force: 60g±15gf
Pre-travel: 1.7±0.4mm
Total travel: 3.5mm
Spring: 16.5mm single stage
Stem: POM
Top Housing: POM
Bottom Housing: POM

Brown Nano (Linear)

Operating Force: 50± 15gf
End Force: 65g±15gf
Pre-travel: 1.7±0.4mm
Total travel: 3.5mm
Spring: 16.5mm single stage
Stem: POM
Top Housing: POM
Bottom Housing: POM

Blush Nano (Silent Linear)

Operating Force: 42± 15gf
End Force: 55g±15gf
Pre-travel: 1.7±0.4mm
Total travel: 3.2±0.2mmmm
Spring: 16.5mm single stage
Stem: POM
Top Housing: PC
Bottom Housing: PA66

Contents
