Appearance

Classic Design, Unmatched Portability

The Agar Mini translates the iconic Agar design language into a more refined and compact form factor, retaining its signature gentle curves while

For ultimate convenience, the Agar Mini comes complete with a bespoke storage pouch. This makes it easy to pack and carry, establishing it as the perfect companion for use at home, in the office, and on the go.

Available PCBs

EC PCB

1.6mm PCB
support VIAL
Magnetic pin header
Daughterboard are included
Switch Compatibility: Naevies EC Switches
Support capslock LED

MX Solder PCB

1.6mm PCB
support VIA/VIAL
Magnetic pin header
Daughterboard are included
Switch Compatibility: MX-style Mechanical Switches
Support capslock LED
Firmware: ydkb_kbdfans_agar_mini_vial.uf2
Json: ydkb_kbdfans_agar_mini_via.json

MX Hotswap PCB

1.6mm PCB
support ZMK
Magnetic pin header
Daughterboard are included
Switch Compatibility: MX-style Mechanical Switches
Firmware: agar_mini-klink-zmk.uf2

Layout

The Agar Mini is built upon a custom 40% layout with a total width of 13 units (13U).

In contrast to more common 12U compact designs, this 13U width offers superior visual and proportional balance.
It elegantly avoids the cramped profile that can result from a 0.5U reduction on the modifiers,
lending the entire chassis a more harmonious and fluid appearance.

In its layout philosophy, the Agar Mini pays homage to the classic HHKB style while utilizing a standard staggered key arrangement.

This thoughtful combination ensures a familiar typing experience, minimizing the learning curve and
making it immediately accessible to a wide range of users.

EC PCB Layout

Hotswap PCB Layout

The Wireless Experience, Perfected: More Stable, Lasts Longer

The Agar Mini marks KBDfans' debut into dual-mode wireless kits powered by ZMK firmware. Setting it apart from conventional solutions on the market, ZMK delivers an exceptionally stable Bluetooth experience, distinguished by its modular architecture and ultra-low power consumption.

Thanks to our meticulous tuning and optimization, the Agar Mini achieves a remarkable battery life of up to 3 months, even with just a 300mAh battery. We didn't stop there; we've further enhanced the native ZMK functionality with several key improvements:

Full Indicator Light Support: We've custom-implemented indicator functionality, a feature not natively available in ZMK.
Optimized Connectivity: Bluetooth connection speed and stability have been significantly improved.
Future-Ready: Seamless integration with the AVA configurator is planned, ensuring an even smoother user experience down the road.
